Factory model |
55Z570RP |
Description |
139cm (55" ) Direct LED Television |
Specifications form version |
HA250120 |
Active display area, horizontal dimension |
1209.6mm |
Active display area, vertical dimension |
680.4mm |
Screen size (rounded to nearest integer) |
139cm |
Screen size (rounded to nearest integer) |
55inch |
Display technology |
LCD/ LED lit |
Backlight source |
Direct LED |
Resolution (Horiz x Vert) |
3840X2160 Pixel |
Screen curvature radius |
– |
Colour depth |
8bit+FRC |
Image refresh frequency |
120Hz |
Smooth motion rate |
240 |
Typical brightness of white |
350nit |
Native contrast ratio |
4000:1 |
Viewing Angle (Horiz / Vert) |
178/ 178 Degree |
Quantum dot |
Yes |
Wide colour gamut |
Yes |
KSF phosphor |
Yes |
UHD Premium |
No |
Response Time |
8ms |
RF- Radio frequency input |
2 |
AV input |
1 |
AV output |
0 |
USB interface type 3.0 (Qty / List….) |
0 |
USB interface type 2.0 (Qty / List ….) |
2/ USB2 |
Optical digital audio output (SPDIF) |
1 |
Earphone jack |
0 |
HDMI inputs |
3 |
HDMI type 8K@60Hz |
No |
HDMI type 4K@60Hz with HDCP version 2.2 |
Yes |
HDMI 2.1 compliant input |
Yes / HDMI 2 & 3 |
Enhanced Audio Return Channel ( eARC) |
Yes / HDMI 2 |
CEC- Consumer Electronics Control via HDMI |
Yes |
Ethernet port (RJ45 connector) |
1 |
Wi-Fi protocols IEEE 802.11 {b, g, n, ac, ad, ..} |
a, b, g, n, ac |
Wi-Fi bands |
2.4/5.0Ghz |
DLNA compliance |
Yes |
Bluetooth / BT version |
Yes / 5.0 |
Anyview ( Screen Sharing) |
Yes |
Catch-up TV services |
Iview, SBS on Demand, 9Now,tenplay |
Installed Applications {List ……} |
Netflix/Youtube/Prime Video…… |
Freeview Plus – HbbTV 2.0 |
Yes |
Web browser [Chrome | Opera | Other] |
Odin |
Digital broadcating (DVB-T / DVB-T2) |
Yes / Yes |
Video decoder (MPEG2 / MPEG 4) |
Yes / Yes |
LCN- Logical channel number and DTV Service name support |
Yes |
Subtitles |
Yes |
EPG- Electronic programming guide, 7 days for all services |
Yes |
Audio description (vision impairment aid) |
Yes |
Parental rating lock |
Yes |
Analog Tuner |
Yes |
Backlight control |
Yes |
Light sensing |
YES |
Dynamic backlight control |
YES |
Frame rate control |
No |
Variable Refresh Rate (VRR) |
Yes |
FreeSync |
Freesync Premium |
Auto Low Latency Mode for VRR |
Yes |
Local dimming/ controllable zones |
No |
Zoom function settings |
Auto/ 16:9/ 4:3/21:9/Movie Zoom/ Dot to Dot |
HDR – High Dynamic Range for luminance (DMP / Netflix / HDMI) |
Yes / Yes/ Yes |
HDR system (HDR10 / HDR10+ / Dolby Vision) |
Yes /Yes/Yes |
HLG (Hybrid Log-Gamma) for HDR |
YES |
HEVC (H.265) decoder |
Yes |
Motion enhancement and compensation (MEMC) |
Yes |
Audio power output per channel |
Main speaker:10W*2 |
Speaker power |
12W6Ω+12W6Ω |
Number of speakers (Tweeter / Midrange / Woofer) |
0 /2 /0 |
Automatic volume level (AVL) |
Yes |
Audio equalizer |
Yes |
Dolby Digital |
Yes |
Audio enhancement -Type {SRS, BBE, SAP, DBX-TV….} |
Dolby ATMOS |
Lip-sync adjustment |
Yes |
On/off timer |
Yes |
Power off if no signal |
Yes |
Sleep timer |
Yes |
Program lock |
Yes |
OSD transparency control |
Yes |
Operating System |
VIDAA U8.5 |
Software version OSD indication |
Yes |
Legal requirements: Disclaimer / Acceptance of Terms |
Yes / Yes |
Favourite channels list |
Yes |
Electronic point of sales (E-POS) |
Yes |
OTA- Over the air software updates |
Yes |
Voice command |
Yes |
Screen Sharing {Miracast, Content Sharing, …} |
Miracast,Content Sharing |
Smartphone remote control application {Rremote Now, …} |
vidaa app |
Replaceable demo video for Store mode |
Yes |
Remote control via serial port |
No |
Personal Video Recorder |
Yes |
Time Shift |
Yes |
DTV Recording (EPG scheduling / start from Standby ) |
Yes / Yes |
DivX decoder |
No |
MPEG4 (H.264) / H.265 decoder |
Yes / Yes |
DMP- Digital media player content (Music / Video / Photos / Text) |
Yes / Yes / Yes / No |
DMP Auto-play |
No |
DMP for UHD content via USB |
Yes |
DMP File allocation table (FAT / FAT32 / exFAT / NTFS) |
Yes / Yes / No / Yes |
PVR File allocation table (FAT / FAT32 / exFAT / NTFS) |
Yes / Yes / No / Yes |
Protected Hotel lock submenu (Password / fixed code) |
No / Yes |
Clone function for programs, sound and image settings. |
Yes |
Sub-menu lock, including tuning lock |
Yes |
Keyboard lock |
Yes |
Maximum volume lock |
Yes |
Power on volume |
Yes |
Power on, apply default sound/image settings |
No |
Power on source selection |
Yes |
Power on RF channel selection |
Yes |
Power on mode (On / Standby / Last) |
Yes / Yes / Yes |
Inputs access (Enable / Disable) |
Yes |
Processor / Cores |
MT9618GADTAB |
Dual Tuner |
No |
Colour (Front bezel, rear, stand) |
玄武锖、黑色、玄武锖 |
Speakers mounted in enclosure |
Yes |
Mains power switch |
No |
Swivel base |
No |
Compact packaging |
Yes |
Supply range [Voltage / Frequency ] |
AC100~240V,50Hz/60Hz |
Rating Power |
130w |
Standby consumption |
< 0.5W |
Maximum time delay Power On to sound an image |
30s |
Stand area (Width / Depth) |
985mm×313mm |
Wall mount dimensions (Horiz x Vert) |
200mm×400mm |
Wall mount, screw thread |
M6/15 |
VESA compliance |
Yes |
Detachable power cord |
Yes |
Power cord length |
155cm |
Battery (size / quantity) |
AAA *2 |
User manual (Available online) / Quick setup guide (Print) |
1/1 |
Warranty [In User manual | In separate sheet] |
In separate sheet |
Dimensions with stand (W x H x D) |
1233mm×766mm×313mm |
Dimensions without stand (W x H x D) |
1233mm×717mm×80mm |
Carton box dimensions (W x H x D) |
1400mm×135mm×846mm |
Net weight (with stand / without stand) |
11.6/11.4 |
Gross weight |
17 |
Container load (20ft / 40ft / 40ft HC) |
140/284/426 |
EMC- Electromagnetic Compatibility |
Yes |
CB- Electrical safety |
Yes |
HDMI |
Yes (Hisense internal test) |
Dolby Digital |
Yes |
MEPS- Test report |
Yes |
ROHS |
Yes |
Electrical safety conformity for Australia |
Yes |
CB report and certificate |
Yes |
EMC report and certificate |
Yes |
Power cord, plug and connector Australian safety approval |
Yes |
